| 形名(電圧-極数-出力) | ||
| 電圧・周波数 | ||
| 出力 | ||
| 極数 | ||
| 定格電流(A) | ||
| 定格回転速度(min-1) | ||
| 使用 | ||
| エネルギー消費効率(%) | ||
| 効率クラス(IEコード) | ||
| 外被構造 | ||
| わく番号 | ||
| 保護方式 | ||
| 概略裸質量(kg) | ||
| 軸端キー・キー溝寸法 | ||
| 動力伝達方式 | ||
| 回転方向 | ||
| 耐熱クラス | ||
| 周囲条件 | 温度 | |
| 湿度 | ||
| 標高 | ||
| 雰囲気 | ||
| 端子箱位置 | ||
| 口出線 | リード本数 | |
| 端子接続方式 | ||
| 塗色 | ||
| 準拠規格 | ||
| 許容慣性モーメント(kgf・m2) | 50Hz | 許容J |
| モータJ | ||
| 60Hz | 許容J | |
| モータJ | ||
| 許容スラスト荷重 | Ａ方向(N) | |
| Ｂ方向(N)*プレロードスプリング入替えが必要 | ||
| 許容ラジアル荷重 | 直結(N) | |
| ベルト(N) | ||
| 騒音レベル（参考値） | 50Hｚ･･･db（A) | |
| 60Hｚ･･･db（A) | ||
| PLG有無 | ||
200 / 200 / 220 / 230V 50 / 60 / 60 / 60Hz |
5.5kW |
2P |
20.6 / 19.8 / 18.4 / 18.0 |
2940 / 3525 / 3540 / 3545 |
S1(連続使用) |
91.2 / 90.9 / 91.5 / 91.7 |
IE3 |
全閉外扇形 |
132S |
IP44 |
50 |
軸端径φ14以上に対応する軸端キー・キー溝の寸法・公差はISO規格と整合性のあるJIS B1301に準拠しています。 |
2極機の11kW以上は直結専用、4極以上は直結・ベルト掛供用。 |
軸端より見て反時計方向（CCW） |
130(B) |
-30℃～40℃ |
100%RH以下(結露が無いこと） |
1000m以下 |
腐食性及び爆発性ガス、蒸気及び結露が無く、塵埃が少ないこと。 |
軸端より見てフレーム左側反負荷側 |
6 |
端子台接続方式[スターデルタ  始動可能] |
マンセルN7 |
JIS C 4213, JEC-2137-2000 |
2.5 |
0.012 |
1.8 |
0.012 |
1020 |
*655 |
1320 |
- |
65 |
69 |
なし |
